Dual general-purpose comparator IC featuring two independent comparator elements. Operates with a minimum dual supply voltage of 1V and a maximum supply voltage of 36V, with a minimum single supply of 2V. Offers a 1.3µs response time and TTL output type, with 18mA output current per channel. Input bias and offset current are 250nA, with an input offset voltage of 5mV. Packaged in an 8-pin SO surface mount configuration, this lead-free and RoHS compliant component has a maximum power dissipation of 710mW.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Stmicroelectronics LM393DT datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SO |
| Input Bias Current | 250nA |
| Input Offset Voltage (Vos) | 5mV |
| Lead Free | Lead Free |
| Min Dual Supply Voltage | 1V |
| Max Input Current | 250nA |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Power Dissipation | 710mW |
| Max Supply Voltage | 36V |
| Min Supply Voltage | 2V |
| Mount | Surface Mount |
| Number of Channels | 2 |
| Number of Elements | 2 |
| Output Current | 18mA |
| Output Current per Channel | 18mA |
| Output Type | TTL |
| Package Quantity | 2500 |
| Packaging | Cut Tape |
| Quiescent Current | 2.5mA |
| Response Time | 1.3us |
| RoHS Compliant | Yes |
| Type | General Purpose |
| Weight | 0.01787oz |
| RoHS | Compliant |
