The STM8SPLNB1P6 is an 8-bit microcontroller with a 16MHz frequency and I2C interface. It is packaged in a TSSOP20 surface mount package and operates over a temperature range of -40°C to 85°C. The device is compliant with RoHS standards and has a maximum power dissipation of 238mW. It is available in a rail/Tube packaging with 74 units per package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Stmicroelectronics STM8SPLNB1P6 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Stmicroelectronics STM8SPLNB1P6 technical specifications.
| Package/Case | TSSOP |
| Data Bus Width | 8b |
| Frequency | 16MHz |
| Interface | I2C |
| Lead Free | Lead Free |
| Max Frequency | 16MHz |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 238mW |
| Max Supply Voltage | 5.5V |
| Memory Type | ROMless, |
| Min Supply Voltage | 2.95V |
| Mount | Surface Mount |
| Number of I/Os | 4 |
| Package Quantity | 74 |
| Packaging | Rail/Tube |
| Peripherals | LVD |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | STM8S |
| RoHS | Compliant |
Download the complete datasheet for Stmicroelectronics STM8SPLNB1P6 to view detailed technical specifications.
