Radial film capacitor featuring PET dielectric, 100nF capacitance, and 250V DC rated voltage with 5% tolerance. This component offers a wide operating temperature range from -55°C to 125°C and a 10mm lead pitch. Constructed with tin, matte contact plating and a 0.5mm lead diameter, it is RoHS compliant and designed for through-hole mounting. Dimensions are 13mm length, 4mm width, and 7mm height, supplied in an ammo pack.
PackageRadial
Capacitance100nF
MountingThrough Hole
Quick Jump:
Technical Specifications
TDK B32521C3104J289 technical specifications.
General
| Capacitance | 100nF |
| Package/Case | Radial |
| Construction | RADIAL |
| Contact Plating | Tin, Matte |
| Depth | 4mm |
| Dielectric | PET |
| Dielectric Material | PET |
| Height | 7mm |
| Lead Diameter | 0.5mm |
| Lead Free | Lead Free |
| Lead Length | 6mm |
| Lead Pitch | 10mm |
| Length | 13mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Package Quantity | 1000 |
| Packaging | Ammo Pack |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | B32521 |
| Termination | Radial |
| Tolerance | 5% |
| Voltage Rating (AC) | 160V |
| DC Rated Voltage | 250V |
| Width | 4mm |
Compliance
| RoHS | Compliant |
