TDK
B32524Q3475K000
CAPACITOR, METALLIZED FILM, POLYESTER, 250 V, 4.7 uF, THROUGH HOLE MOUNT, RADIAL LEADED, LEAD FREE
PackageRadial
Capacitance4.7uF
Voltage Rating250V
Quick Jump:
Technical Specifications
TDK B32524Q3475K000 technical specifications.
General
Capacitance
4.7uF
Package/Case
Radial
Construction
RADIAL
Depth
11mm
Dielectric
PET
Dielectric Material
PET
Flammability Rating
UL94 V-0
Lead Diameter
0.8mm
Lead Pitch
27.5mm
Length
31.5mm
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Packaging
Bulk
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
B32524
Termination
PC Pins
Tolerance
10%
Voltage Rating
250V
Voltage Rating (AC)
160V
DC Rated Voltage
250V
Compliance
RoHS
Compliant
