TDK's B57251V5103J060 is a 10kR 5% SMD/SMT resistor with a maximum power dissipation of 150mW. It is available in a 0402 package with a depth of 0.5mm, height of 1.3mm, and length of 2mm. The resistor operates within a temperature range of -40°C to 150°C and is compliant with RoHS regulations. It is not Reach SVHC compliant and is part of the Automotive, AEC-Q200 series.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TDK B57251V5103J060 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Case Code (Imperial) | 0402 |
| Case Code (Metric) | 1005 |
| Package/Case | 0402 |
| Depth | 0.5mm |
| Height | 1.3mm |
| Length | 2mm |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 150mW |
| Package Quantity | 10000 |
| Packaging | Tape and Reel |
| Reach SVHC Compliant | No |
| Resistance | 10kR |
| Resistance Tolerance | 5% |
| RoHS Compliant | Yes |
| Series | Automotive, AEC-Q200, B572xxV5 |
| Termination | SMD/SMT |
| Tolerance | 5% |
| Width | 1.25mm |
| RoHS | Compliant |
