Radial leaded, through-hole mount metal oxide varistor (MOV) for circuit protection. Features a 27V varistor voltage with a tolerance of 10%, and a DC rated voltage of 22V (AC rated voltage of 17V). Offers a clamping voltage of 53V at 5A clamping current, with a maximum surge current capability of 500A. Energy rating is 2.5J, with a capacitance of 4.35nF. Operates within a temperature range of -40°C to 85°C, with tin contact plating and a 7.5mm lead pitch.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TDK B72210S0170K101 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Capacitance | 4.35nF |
| Clamping Current | 5A |
| Clamping Voltage | 53V |
| Contact Plating | Tin |
| Depth | 4.4mm |
| Diameter | 10mm |
| Energy | 2.5J |
| Lead Length | 30mm |
| Lead Pitch | 7.5mm |
| Lead/Base Style | Radial |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Surge Current | 500A |
| Max Varistor Voltage | 29.7V |
| Min Varistor Voltage | 24.3V |
| Max Voltage Rating (AC) | 17V |
| Max Voltage Rating (DC) | 22V |
| Mount | Through Hole, Radial |
| Number of Circuits | 1 |
| Package Quantity | 500 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | Standard |
| Thickness | 4.4mm |
| Tolerance | 10% |
| Varistor Voltage | 27V |
| Voltage Rating (AC) | 17V |
| DC Rated Voltage | 22V |
| Weight | 0.070548oz |
| RoHS | Compliant |
