This SIDAC from TDK features a radial lead style with a 10mm pitch, suitable for through hole mounting. The device has a maximum operating temperature of 85°C and a minimum operating temperature of -40°C. It is compliant with UL94 V-0 flammability rating and lead free. The SIDAC has a varistor voltage of 680V, a voltage rating of 420V AC and 585V DC, and a voltage tolerance of 10%.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TDK B72220S421K101 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
TDK B72220S421K101 technical specifications.
| Capacitance | 420pF |
| Package/Case | Radial |
| Clamping Current | 100A |
| Clamping Voltage | 1.12kV |
| Depth | 6.5mm |
| Flammability Rating | UL94 V-0 |
| Lead Free | Lead Free |
| Lead Pitch | 10mm |
| Lead/Base Style | Radial |
| Material | Metal |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Surge Current | 8kA |
| Max Voltage Rating (AC) | 420V |
| Max Voltage Rating (DC) | 585V |
| Mount | Through Hole |
| Packaging | Bulk |
| Reach SVHC Compliant | Unknown |
| Series | Standard |
| Varistor Voltage | 680V |
| Voltage Rating (AC) | 420V |
| DC Rated Voltage | 560V |
| Voltage Tolerance | 10% |
| RoHS | Compliant |
