100W, 12V DC/DC converter module with 8.3A output current. Features 90-264V AC input, 89% efficiency, and 4kV isolation voltage. Operates from 0°C to 70°C with CE approval and RoHS compliance. Designed for board mount applications with a 5 x 3 x 1.3 inch footprint.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TDK CSS150-12 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
TDK CSS150-12 technical specifications.
| Approvals | CE |
| Current - Output 1 | 8.3A |
| Depth | 76.2mm |
| Efficiency | 89% |
| Height | 1.3inch |
| Isolation Voltage | 4kV |
| Length | 5inch |
| Max Input Voltage (AC) | 264V |
| Min Input Voltage (AC) | 90V |
| Max Input Voltage | 264V |
| Min Input Voltage | 90V |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Output Current | 8.3A |
| Max Output Power | 100W |
| Max Power Dissipation | 100W |
| Mount | Chassis Mount, Panel, Screw |
| Nominal Output Voltage | 12V |
| Number of Outputs | 1 |
| Output Current | 8.3A |
| Output Power | 100W |
| Output Voltage | 12V |
| Package Quantity | 1 |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | CSS150 |
| Voltage - Output 1 | 12V |
| Weight | 12oz |
| Width | 3inch |
| RoHS | Compliant |
