The CSS150-48 DC/DC converter from TDK offers 48V output voltage with a maximum output current of 3.1A and efficiency of 89%. It features 4kV isolation voltage and operates within a temperature range of 0°C to 70°C. The converter is designed for chassis mount, panel, or screw mounting and is compliant with CE regulations.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TDK CSS150-48 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
TDK CSS150-48 technical specifications.
| Approvals | CE |
| Current - Output 1 | 3.1A |
| Efficiency | 89% |
| Height | 1.3inch |
| Isolation Voltage | 4kV |
| Length | 5inch |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Output Current | 2.1A |
| Max Power Dissipation | 100W |
| Mount | Chassis Mount, Panel, Screw |
| Number of Outputs | 1 |
| Output Current | 3.1A |
| Output Power | 101W |
| Output Voltage | 48V |
| Package Quantity | 1 |
| RoHS Compliant | Yes |
| Series | CSS150 |
| Voltage - Output 1 | 48V |
| Weight | 12oz |
| Width | 3inch |
| RoHS | Compliant |
