Single-output AC/DC power supply delivering 36V at 2.1A, with a maximum output power of 76W. Features include 86% efficiency, 3kV isolation voltage, and a wide AC input range of 88-264V. Operates across a temperature range of -25°C to 70°C and is CE and RoHS compliant. Designed for chassis or panel mounting.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TDK LS75-36 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
TDK LS75-36 technical specifications.
| Approvals | CE |
| Current - Output 1 | 2.1A |
| Depth | 96.52mm |
| Efficiency | 86% |
| Height | 1.5inch |
| Input Current | 1A |
| Isolation Voltage | 3kV |
| Length | 5.1inch |
| Max Input Voltage (AC) | 264V |
| Min Input Voltage (AC) | 88V |
| Max Input Voltage | 264V |
| Min Input Voltage | 88V |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -25°C |
| Max Output Current | 2.1A |
| Max Output Power | 75.6W |
| Max Power Dissipation | 75W |
| Mount | Chassis Mount, Panel |
| Nominal Output Voltage | 36V |
| Number of Outputs | 1 |
| Output Current | 2.1A |
| Output Power | 76W |
| Output Voltage | 36V |
| Package Quantity | 1 |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | LS |
| Voltage - Output 1 | 36V |
| Weight | 8.81849oz |
| Width | 3.8inch |
| RoHS | Compliant |
