Enclosed AC/DC power supply featuring three outputs: 5V at 3A, 15V at 600mA, and -15V at 400mA, delivering a total of 17W maximum output power. This chassis mountable unit operates from 85-265V AC input, boasts 3kV isolation voltage, and achieves 72% efficiency. Designed for a 0°C to 60°C operating temperature range, it meets CE, UL, and CSA approvals.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TDK LWT-15H-5FF datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
TDK LWT-15H-5FF technical specifications.
| Approvals | CE, UL, CSA |
| Current - Output 1 | 3A |
| Current - Output 2 | 600mA |
| Current - Output 3 | 400mA |
| Depth | 60mm |
| Efficiency | 72% |
| Height | 0.98inch |
| Isolation Voltage | 3kV |
| Lead Free | Lead Free |
| Length | 5.03inch |
| Max Input Voltage (AC) | 265V |
| Min Input Voltage (AC) | 85V |
| Max Input Voltage | 265V |
| Min Input Voltage | 85V |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | 0°C |
| Max Output Current | 3A |
| Max Output Power | 17W |
| Max Power Dissipation | 15W |
| Mount | Chassis Mount, Panel |
| Number of Outputs | 3 |
| Output Current | 3A |
| Output Power | 17W |
| Output Voltage | 5V |
| Package Quantity | 1 |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | No |
| Series | LW |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | 15V |
| Voltage - Output 3 | -15V |
| Weight | 1.609lb |
| Width | 2.36inch |
| RoHS | Not CompliantNo |
