Through-hole mounted data line filter featuring a single function. With a 3V DC rated voltage and 3V operating supply voltage, this component operates across a frequency range of 4kHz. Its dimensions include a 12.2mm diameter and 6.5mm height. The filter is lead-free, RoHS compliant, and supplied on tape and reel in quantities of 2500.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TDK PS1240P02BT datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Diameter | 12.2mm |
| Frequency | 4kHz |
| Height | 6.5mm |
| Lead Free | Lead Free |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -10°C |
| Mount | Through Hole |
| Operating Supply Voltage | 3V |
| Package Quantity | 2500 |
| Packaging | Tape and Reel |
| RoHS Compliant | Yes |
| Series | PS |
| Termination | PC Pins |
| DC Rated Voltage | 3V |
| RoHS | Compliant |
