Benchtop AC-DC power supply, 200W maximum output power, delivering 0-10V adjustable output voltage and up to 20A maximum output current. Features a digital display for precise monitoring, 82% efficiency, and operates within a 0°C to 50°C temperature range. Input voltage range is 85-265V AC. Dimensions are 70mm width, 83mm height, and 350mm length. RoHS compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TDK Z10-20-U datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Current - Output 1 | 20A |
| Display Type | Digital |
| Efficiency | 82% |
| Height | 83mm |
| Length | 350mm |
| Max Operating Temperature | 50°C |
| Min Operating Temperature | 0°C |
| Max Output Current | 20A |
| Max Output Power | 200W |
| Max Output Voltage | 10V |
| Min Output Voltage | 0V |
| Max Power Dissipation | 200W |
| Max Supply Voltage (AC) | 265V |
| Min Supply Voltage (AC) | 85V |
| Number of Outputs | 1 |
| Output Current | 20A |
| Output Power | 200W |
| Output Voltage | 10V |
| Package Quantity | 1 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | Z+ |
| Voltage - Output 1 | 10V |
| Weight | 4.2lb |
| Width | 70mm |
| Wire/Cable Type | Power Cord |
| RoHS | Compliant |
