Programmable AC/DC power supply offering 0-100V output voltage and up to 8A maximum output current, delivering 800W maximum output power. Features a digital display for precise monitoring and control. Operates within an AC input voltage range of 85V to 265V, with an efficiency of 86%. Compact design with dimensions of 70mm width, 83mm height, and 350mm length. RoHS compliant for environmental considerations.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TDK Z100-8-LAN-U datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
TDK Z100-8-LAN-U technical specifications.
| Current - Output 1 | 8A |
| Display Type | Digital |
| Efficiency | 86% |
| Height | 83mm |
| Length | 350mm |
| Max Operating Temperature | 50°C |
| Min Operating Temperature | 0°C |
| Max Output Current | 8A |
| Max Output Power | 800W |
| Max Output Voltage | 100V |
| Min Output Voltage | 0V |
| Max Power Dissipation | 800W |
| Max Supply Voltage (AC) | 265V |
| Min Supply Voltage (AC) | 85V |
| Number of Outputs | 1 |
| Output Current | 8A |
| Output Power | 800W |
| Output Voltage | 100V |
| Packaging | Bulk |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | Z+ |
| Voltage - Output 1 | 100V |
| Weight | 4.2lb |
| Width | 70mm |
| Wire/Cable Type | Power Cord |
| RoHS | Compliant |
