Bench power supply with a single output, delivering 0V to 36V and up to 12A, for a maximum power of 432W. Features digital display, 0.02% accuracy, and 84% efficiency. Operates from 0°C to 50°C, with UL and CE approvals. Rack-mountable design, 70mm depth, 4.88-inch height, 391mm length, and 2.76-inch width. RoHS compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TDK ZUP36-12/U datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Accuracy | 0.02% |
| Approvals | UL, CE |
| Current - Output 1 | 12A |
| Depth | 70mm |
| Display Type | Digital |
| Efficiency | 84% |
| Frequency | 63Hz |
| Height | 4.88inch |
| Length | 391mm |
| Max Operating Temperature | 50°C |
| Min Operating Temperature | 0°C |
| Max Output Current | 12A |
| Max Output Power | 432W |
| Max Power Dissipation | 400W |
| Mount | Rack |
| Number of Characters | 3 |
| Number of Outputs | 1 |
| Output Current | 12A |
| Output Power | 432W |
| Output Voltage | 36V |
| Packaging | Bulk |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | ZUP |
| Voltage - Output 1 | 36V |
| Weight | 7.1lb |
| Width | 2.76inch |
| RoHS | Compliant |
