Brauer is a British manufacturer established in 1926 that specializes in a wide range of industrial products. The companys offerings include heavy-duty industrial wheels, castors, axles, and toggle clamps.
TOGGLE CLAMP; Clamp Type:Push Pull; Holding Force:600N; Height:130mm; Length:127mm; Weight:0.55kg; Vertical Arm Length:130mm; Hole Diameter:14mm
TOGGLE CLAMP; Clamp Type:Horizontal; Holding Force:50N; Height:22mm; Length:70mm; Weight:0.036kg; Vertical Arm Length:-; Hole Diameter:4.2mm; Hole Centres:16 x 16 ;RoHS Compliant: NA
TOGGLE CLAMP; Clamp Type:Horizontal; Holding Force:75N; Height:36mm; Length:116mm; Weight:0.1kg; Vertical Arm Length:-; Hole Diameter:5.2mm; Hole Centres:16.8 x 13.5 ;RoHS Compliant: NA
PRESS, MANUAL ASSEMBLY; Stroke Length Max:32mm; Overall Height:232mm; Force Capacity:-; Height:232mm; Holding Force:600kg; Throat Capacity:50mm; Weight:3.6kg; Working Distance:75mm ;RoHS Compliant: NA
PRESS, MANUAL ASSEMBLY; Stroke Length Max:50mm; Overall Height:330mm; Force Capacity:-; Height:330mm; Holding Force:1200kg; Throat Capacity:60mm; Weight:7.35kg; Working Distance:100mm ;RoHS Compliant: NA
TOGGLE CLAMP; Clamp Type:Vertical; Holding Force:1500N; Height:125mm; Length:70mm; Weight:150g; Vertical Arm Length:125mm; Hole Diameter:5.1mm; Hole Centres:27 x 12.7 ;RoHS Compliant: NA
PRESS, MANUAL ASSEMBLY - Stroke Length Max:75mm; Overall Height:468mm; Height:468mm; Holding Force:2500kg; Throat Capacity:75mm;
TOGGLE CLAMP; Clamp Type:Vertical; Holding Force:2500N; Height:175mm; Length:110mm; Weight:380g; Vertical Arm Length:175mm; Hole Diameter:7.1mm; Hole Centres:32 x 19
HMC BRAUER - P50 - TOGGLE CLAMP, PUSH PULL
TOGGLE CLAMP; Clamp Type:Push Pull; Holding Force:2500N; Height:280mm; Length:297mm; Weight:4.15kg; Vertical Arm Length:280mm; Hole Diameter:10.3mm
TOGGLE CLAMP; Clamp Type:Push Pull; Holding Force:1200N; Height:200mm; Length:190mm; Weight:1.6kg; Vertical Arm Length:200mm; Hole Diameter:20mm
HMC BRAUER - V75/2B - TOGGLE CLAMP
TOGGLE CLAMP; Clamp Type:Horizontal; Holding Force:250N; Height:67mm; Length:224mm; Weight:0.5kg; Vertical Arm Length:-; Hole Diameter:6.6mm; Hole Centres:31 x 26 ;RoHS Compliant: NA
TOGGLE CLAMP, PUSH PULL; Clamp Type:Push Pull; Holding Force:600N; Height:67mm; Length:127mm; Weight:0.45kg; Vertical Arm Length:-; Hole Diameter:5.5mm
Brauer H150/2B Horizontal Toggle Clamp
Brauer V350/2B Vertical Toggle Clamp
