Unshrouded header, 3 positions, 2.54mm pitch, straight orientation, solder termination, through-hole mount. Features male pin contacts made of bronze and brass with gold plating, offering a 3A current rating and 750V AC voltage rating. Operates within a temperature range of -40°C to 105°C. Housing is black, with a SIL package type.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Harwin M20-9990345 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SIL |
| Color | Black |
| Contact Material | Bronze, Brass |
| Contact Mating Length | 0.24inch |
| Contact Plating | Gold |
| Contact Type | Male Pin |
| Current Rating | 3A |
| Depth | 2.54mm |
| Housing Color | Black |
| Length | 7.62mm |
| Max Current Rating | 3A |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Contacts | 3 |
| Number of Positions | 3 |
| Number of Rows | 1 |
| Orientation | Straight |
| Package Quantity | 1000 |
| Packaging | Bulk |
| Pitch | 2.54mm |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | M20 |
| Termination | Solder |
| Voltage Rating (AC) | 750V |
| Weight | 0.006138oz |
| RoHS | Compliant |
Download the complete datasheet for Harwin M20-9990345 to view detailed technical specifications.
