Search Results for "GAL"

Filters

DAN-F10Nu-blox F10 standard precision GNSS

u-blox

L1/L5 dual-band GNSS antenna module, 56-pin LCC, 1 m CEP, UART

Datasheet

56-pin LCC (surface-mount)

Active

GNSS constellations: GPS/QZSS (L1 C/A, L5); Galileo (E1B/C, E5a); BeiDou (B1C, B2a); NavIC (L5)

Augmentation systems: SBAS (EGNOS, WAAS, GAGAN, MSAS, BDSBAS, KASS, SouthPAN); QZSS L1S/L1Sb

Navigation update rate: Up to 10Hz

Horizontal position accuracy (CEP): 1.0 (with SBAS); 1.5 (without SBAS)m

QRB2210Robotics RB1 Platform

Qualcomm

Quad‑core Cortex‑A53 SoC, Adreno 702 GPU, 1080p H.264/H.265, dual ISP, USB 3.1

Datasheet

752‑ball NSP BGA, 12.0 × 12.4 × 0.91 mm, 0.4 mm pitch

Active

CPU architecture: Arm Cortex‑A53, 64‑bit quad‑core

CPU clock: Up to 2.0GHz

GPU: Adreno 702 @ 845 MHz, 64‑bit addressing

DSP: Dedicated DSP shared between sensor core and low‑power audio subsystem

CGGP.25.4.E.02CGGP

Taoglas Limited

Taoglas CGGP.25.4.E.02 25x25x4mm GPS/GLONASS/Galileo Dual-Band Ceramic Patch Antenna

Datasheet

Ceramic Patch

Active

Center Frequency (GPS/Galileo): 1575.42MHz

Center Frequency (GLONASS): 1602MHz

Peak Gain (GPS/Galileo): 5.39dBi

Peak Gain (GLONASS): 5.46dBi

BG77LA-64-SGNSBG77

QUECTEL WIRELESS SOLUTIONS CO., LTD.

Quectel BG77 LTE Cat M1/NB2 LPWA Module with Integrated GNSS

Datasheet

LGA

Active

Technology: LTE Cat M1 / Cat NB2 / GNSS

Supply Voltage (Typical): 3.3V

Supply Voltage (Range): 2.6 - 4.8V

Data Rate DL (Cat M1): 588kbps

AP.17E.07.0064A

Taoglas

1.575GHz GPS/Galileo Active Patch Antenna, 15dB Gain, 17x17x6.3mm

Datasheet

Volume Production

Frequency: 1.57542GHz

Gain: 15dB

Height: 6.3mm

Impedance: 50R

M20050-1RADIONOVA

Antenova

RADIONOVA GNSS Receiver Module (GPS/GLONASS/GALILEO/BEIDOU)

Datasheet

SMD Module

Active

Chipset: MediaTek MT3333

Frequency: 1559 – 1609MHz

Acquisition Sensitivity: -148dBm

Tracking Sensitivity: -165dBm

EC21EFA-512-STDEC21

QUECTEL WIRELESS SOLUTIONS CO., LTD.

Quectel EC21EFA-512-STD LTE Cat 1 Module with 2G/3G Fallback and GNSS

Datasheet

LCC

Active

LTE Category: Cat 1

Maximum Download Speed: 10Mbps

Maximum Upload Speed: 5Mbps

Supply Voltage (Min): 3.3V

UPD78F0536AGC-GAL-AX

Renesas

8-Bit MCU, 20MHz, 96KB Flash, 55 I/O, 64LQFP, Industrial

Datasheet

Not Recommended for New Design

JESD-30 Code: S-PQFP-G64

JESD-609 Code: e4

Length: 14mm

Max Frequency: 20MHz

UPD78F0532AGC-GAL-AX

Renesas

8-Bit MCU, 20MHz, 24KB Flash, 55 I/O, 64LQFP, Industrial

Datasheet

Not Recommended for New Design

JESD-30 Code: S-PQFP-G64

JESD-609 Code: e4

Length: 14mm

Max Frequency: 20MHz

33-3710-01-01TW3000

Tallysman Wireless Inc

Tallysman TW3710 High Precision Single Band GNSS Antenna, TNC Female, White Conical Radome

Datasheet

Panel Mount

Active

Frequency Range: 1557 to 1606MHz

LNA Gain: 28dB

Supply Voltage: 2.5 to 16VDC

Supply Current: 15mA

BG95M1LA-64-SGNSBG95

Quectel Wireless Solutions Co., Ltd.

Quectel BG95M1LA-64-SGNS LTE Cat M1 LPWA Module with GNSS

Datasheet

LGA

Active

Technology: LTE Cat M1

GNSS Support: GPS, GLONASS, BeiDou, Galileo, QZSS

Max Downlink Data Rate: 588kbps

Max Uplink Data Rate: 1119kbps

GAL26V12C-15LJN

Lattice Semiconductor

SPLD GAL Family 12 Macro Cells 83.3MHz 5V 28-Pin PLCC

Datasheet

Volume Production

Package/Case: PLCC

Frequency: 83.3MHz

Max Operating Temperature: 75°C

Min Operating Temperature: 0°C

ES132

ITW

Aqueous Flux Remover - 1 Gal

Datasheet

Volume Production

Reach SVHC Compliant: Unknown

RoHS Compliant: Yes

Series: Flux-Off® Aqueous

GALI-21+

Mini-Circuits

8GHz Single Channel RF Amplifier, 3.5V, 40mA, Surface Mount, -45°C to 85°C

Datasheet

Volume Production

Frequency: 8GHz

Max Operating Temperature: 85°C

Min Operating Temperature: -45°C

Max Supply Voltage: 4.1V

GAL16LV8D-5LJN

Lattice Semiconductor

SPLD GAL Family 8 Macro Cells 166MHz 3.3V 20-Pin PLCC

Datasheet

LCC

Obsolete

Package/Case: PLCC

Frequency: 166MHz

Lead Free: Lead Free

Max Frequency: 166MHz

GAL26CV12B-15LJN

Lattice Semiconductor

SPLD GAL Family 12 Macro Cells 83.3MHz 5V 28-Pin PLCC

Datasheet

Volume Production

Package/Case: PLCC

Frequency: 83.3MHz

Max Operating Temperature: 75°C

Min Operating Temperature: 0°C

GALI-51F+

Mini-Circuits

4GHz Single Channel RF Amplifier, Surface Mount, 4.4V 50mA

Datasheet

Volume Production

Frequency: 4GHz

Max Operating Temperature: 85°C

Min Operating Temperature: -45°C

Max Supply Voltage: 5V

GALI-5+

Mini-Circuits

RF Amp Chip Single GP 4GHz 4.9V 4-Pin(3+Tab) Case DF782

Datasheet

Volume Production

Frequency: 4GHz

Max Operating Temperature: 85°C

Min Operating Temperature: -45°C

Max Supply Voltage: 4.9V

GAL16V8D-10LPN

Lattice Semiconductor

SPLD GAL Family 8 Macro Cells 83.3MHz 5V 20-Pin PDIP

Datasheet

DIP

Obsolete

Package/Case: PDIP

Frequency: 83.3MHz

Lead Free: Lead Free

Max Frequency: 83.3MHz

1638-G

Techspray

Flux Remover, 1 gal Bulk

Datasheet

Volume Production

Package Quantity: 1
