Pantheon MA760 4in1 Permanent Mount Antenna (GNSS, MIMO 5G/4G, Wi-Fi)

Permanent Mount Dome

Active

Configuration: 4in1 (1xGNSS, 2xCellular MIMO, 1xWi-Fi)

Frequency Range (Cellular): 600-6000MHz

Frequency Range (Wi-Fi): 2.4/5.0/5.8GHz

Ingress Protection: IP67IP Rating

SR4G008Sinica (lamiiANT)

Antenova

Sinica GNSS SMD Antenna 1559-1609 MHz

SMD

Active

Frequency Range: 1559 – 1609MHz

Peak Gain: 1.5dBi

Average Efficiency: >60%

Maximum VSWR: 1.4:1ratio

Distributor	Stock	1+	10+	25+	100+
TME	1,000	$1.34	$1.22	$1.16	$1.1

33-VSP6337L-01VeroStar

VeroStar Triple-band GNSS Precision Antenna + L-band

Pole Mount / Housed

Active

LNA Gain: 37dB

Noise Figure: 1.8dB

Phase Centre Variation: ±2mm

Supply Voltage Range: 3.0 to 16.0VDC

SKY65723-81GNSS LNA FEM

Skyworks Solutions

Dual-Band Shielded LNA Front-End Module (FEM)

MCM (Multi-Chip Module)

Active

Operating Frequency Range: 1559 - 1606MHz

Gain: 18.5dB

Noise Figure: 0.75dB

Supply Voltage: 1.62 - 3.3V

MA145.A.LBC.001Olympian II

Olympian II 3-in-1 GNSS, LTE, and Wi-Fi 2.4GHz Dome Antenna

Dome / Panel Mount

Active

Frequency Range (Cellular): 617 to 5850MHz

Frequency Range (Wi-Fi): 2.4 to 2.5GHz

Max Gain (Cellular): 3.8dBi

Max Gain (Wi-Fi): 3.5dBi

33-7872-07Accutenna

TW7872 Embedded Dual Band High Gain GNSS Antenna (L1/L2, G1/G2, E1/E5b, B1/B2)

Embedded (Pinned OEM)

Active

LNA Gain: 32dB

Operating Voltage: 2.5 to 16VDC

Supply Current: 24mA

Noise Figure: 2.5dB

MA241.BI.001Genesis

Genesis 2in1 Adhesive Mount Antenna - 4G/3G/2G & GNSS

Adhesive Mount Module

Active

Frequency - Cellular: 698-960 / 1710-2170 / 2300-2700MHz

Frequency - GNSS: 1561 / 1575.42 / 1602MHz

Antenna Gain (GNSS): 30.0dBic

Impedance: 50Ohms

33-HC882-28HC (Helical)

Dual-Band Helical Antenna (L1/L2), 28dB Gain

Screw Mount (SMA Male)

Active

Antenna Gain: 3.5dBic

LNA Gain: 28dB

Frequency Range L1: 1559-1606MHz

Frequency Range L2: 1217-1254MHz

33-3742-01-01TW3742

High Gain Multi-Constellation GNSS Antenna, 1.5815GHz, 40dB Gain

Through-Hole Mount (Bolt)

Active

LNA Gain: 40dB

Center Frequency: 1.5815GHz

Supply Voltage: 2.5 to 16VDC

Current Consumption: 19mA

MA250.A.LBI.001Roadmarker

Roadmarker MA250 2-in-1 LTE and GNSS Adhesive Mount Antenna

Adhesive Mount / Low Profile

Active

Antenna Type: Dome / Road Marker

Number of Bands: 2

Frequency Range (Cellular): 698-960 / 1710-2170MHz

Frequency (GNSS): 1561 / 1575.42 / 1602MHz

A5100AA5100

Lantronix

A5100A Concurrent GNSS Receiver Module

SMT

Obsolete

Voltage - Supply: 3.0 to 3.6V

Operating Temperature: -40 to 85°C

Frequency: 1.575 / 1.602GHz

Sensitivity: -165dBm

33-VSP6037L-01VeroStar

VeroStar VSP6037L Full GNSS Precision Antenna + L-Band

Housed Antenna with TNC Female Connector

Active

LNA Gain: 37dB

Phase Center Variation: ± 2mm

Supply Voltage Range: 3.0 to 16VDC

Current Consumption: 60mA

MA412.A.BI.003Storm

Storm 3-in-1 Combination Screw Mount Antenna (LTE/Wi-Fi/GNSS)

Screw Mount Dome

Active

Antenna Type: External Dome

Frequency Range (LTE): 698-960, 1710-2170, 2490-2690MHz

Frequency Range (Wi-Fi): 2.4, 5.8GHz

Gain (LTE): 6.4dBi

33-VSP6337L-58VeroStar

VeroStar VSP6337L Triple-Band GNSS Precision Antenna + L-band (5/8" Pole Mount)

Radome

Active

LNA Gain: 37dB

Supply Voltage Range: 3.0 to 16VDC

Supply Current: 50mA

Noise Figure: 1.8dB

MA104.C.AB.015Hercules

Hercules 2-in-1 GPS-Glonass & Cellular Permanent Mount Antenna

Module (Screw Mount)

Active

Antenna Type: Combination

Communication Standard: GPS/Glonass/Cellular

Cellular Frequency Range: 824-2170MHz

GNSS Frequency Range: 1574.42-1610MHz

AA.175.301111MagmaX2

MagmaX2 External Multi-Band GNSS Automotive Magnetic Mount Antenna

Magnetic Mount Enclosure

Active

Frequency Range L1: 1559 to 1610MHz

Frequency Range L2: 1227.6MHz

Gain (Max Active): 28dBi

Passive Gain at Zenith: 3.8dBi

MA750.W.A.ABICG.003Pantheon

Pantheon II 5-in-1 Combo Antenna (LTE/Wi-Fi/GNSS)

Permanent Mount Dome

Active

Number of Antennas: 5count

Operating Temperature: -40 to +85°C

Ingress Protection: IP67IP Rating

LTE Gain: 4.0dBi

33-7972-00-3000TW7000

Triple-band Accutenna® GNSS Antenna (L1/L2/L5 + L-Band)

Permanent Mount (Screw Mount)

Active

GNSS Frequencies: 1164-1254, 1559-1610MHz

LNA Gain: 32dB

Supply Current: 24mA

Supply Voltage: 2.5 to 16VDC

33-HC871-28HC (Helical)

HC871 Dual-Band GNSS Helical Antenna, 28dB

Screw Mount / Connector Mount

Active

Antenna Gain: 2.5dBi

LNA Gain: 28dB

Frequency Range Min: 1.217GHz

Frequency Range Max: 1.606GHz

GAL26V12C-15LJN

Lattice Semiconductor

SPLD GAL Family 12 Macro Cells 83.3MHz 5V 28-Pin PLCC

Volume Production

Package/Case: PLCC

Frequency: 83.3MHz

Max Operating Temperature: 75°C

Min Operating Temperature: 0°C
